APC by Schneider Electric Smart-UPS SRT Double Conversion Online UPS - 5 kVA/4.50 kW

  • Part: 1164463
$9,287.00

Availability

Out of Stock

High availability, ruggedized power protection for shipboard and other transportation applications.

Mobile applications present their own unique challenges. Resilience to elevated levels of vibration, conformance to international maritime regulations, such as DNV, enhanced electric hazard protection and ruggedized enclosure are just a few features that are commonly required in mobile applications. APC by Schneider Electric offers customized solutions to meet the demanding requirements for marine, shipboard and other mobile applications.

  • General Information
    • Manufacturer
    • Schneider Electric SA
    • Manufacturer Website Address
    • http://www.schneider-electric.com.au
    • Brand Name
    • APC by Schneider Electric
    • Product Line
    • Smart-UPS SRT
    • Product Type
    • Double Conversion Online UPS
  • Warranty
    • Limited Warranty
    • 3 Year

  • Technical Information
    • Plug/Connector Type
    • Hard Wire 3 wire (1PH+N+G)
    • Receptacle Type
    • IEC 60320 C13
    • IEC Jumper
    • IEC 60320 C19
    • Receptacle Detail
    • 6 x IEC 60320 C13
    • 2 x IEC Jumper
    • 4 x IEC 60320 C19
  • Power Description
    • Load Capacity (VA)
    • 5 kVA
    • Load Capacity (Watt)
    • 4.50 kW
    • Input Voltage
    • 230 V AC
    • Input Voltage Range
    • 160 V AC - 275 V AC
    • Output Voltage
    • 220 V AC
    • 230 V AC
    • 240 V AC
    • Waveform Type
    • Pure Sine Wave
  • Interfaces/Ports
    • Network (RJ-45)
    • Yes
  • Battery Information
    • Backup/Run Time (Full Load)
    • 4 Minute
    • Hot Swappable
    • Yes
  • Physical Characteristics
    • Color Family
    • Black
    • Height
    • 130 mm
    • Width
    • 432 mm
    • Depth
    • 719 mm
    • Form Factor
    • Rack-mountable
    • Weight (Approximate)
    • 54.43 kg
  • Miscellaneous
    • Environmentally Friendly
    • Yes
