- General Information
- Manufacturer
- CyberPower Systems, Inc
- Manufacturer Website Address
- https://www.cyberpower.com/au
- Brand Name
- CyberPower
- Product Type
- Double Conversion Online UPS
CyberPowerOLS10KERT5U is a high-efficiency UPS featuring online double-conversion topology, which provides seamless Pure Sine Wave power for mission-critical devices such as NAS, servers, DVRs/surveillance systems, transportation, infrastructure, and emergency systems. It's typically integrated into the back office, server room, and data center environment.
With high output power factor, the UPS in a smaller footprint can provide more usable power and save rack space. The product allows multiple UPS units to be connected in parallel, achieving higher capacity and power redundancy. The pre-installed Maintenance Bypass PDU (MBP) offers quick and safe maintenance without power interruption. Moreover, the UPS is equipped with Remote Cloud Card to support remote monitoring via a web portal and the mobile app. The tiltable color LCD comes with an intuitive and graphical interface, allowing users to monitor and configure settings with ease. Besides, the battery charging current is adjustable via LCD setting to shorten charging time. It is also designed with relay-type dry contact port to support specific UPS event notifications for easy management.
- Technical Information
- Plug/Connector Type
- Terminal Block
- Receptacle Type
- Terminal Block
- Receptacle Detail
- 1 x Terminal Block
- Overload Protection
- Yes
- EMI/RFI Noise Filter
- Yes
- Phase
- Single Phase
- Application/Usage
- Mission Critical Equipment
- NAS Storage Device
- Server
- DVR
- Surveillance System
- Transportation
- Infrastructure
- Emergency System
- Office
- Server Room
- Data Center
- Power Description
- Load Capacity (VA)
- 10 kVA
- Load Capacity (Watt)
- 10 kW
- Input Voltage
- 120 V AC
- 230 V AC
- Input Voltage Range
- 110 V AC - 300 V AC
- Output Voltage
- 200 V AC
- 208 V AC
- 220 V AC
- 230 V AC
- 240 V AC
- Input Frequency
- 60 Hz
- Output Frequency
- 60 Hz
- Waveform Type
- Pure Sine Wave
- Surge Energy Rating
- 1335 J
- Input Power Factor
- 0.99
- Output Power Factor
- 1
- Display & Graphics
- Display
- LCD/LED
- Management
- Network Management
- SNMP/HTTP Remote Monitoring
- Alarm
- Battery Mode
- Low Battery
- Overload
- Over Charge
- Overheat
- UPS Fault
- Replace Battery
- Controls/Indicators
- Status Indicators
LCD Information Display:
- Operation Type
- Power Status
- Battery Status
- Load Status
- Fault & Warning
- Other Information
- Event & Log
LED Indicators:
- Power On
- Interfaces/Ports
- Serial Port
- Yes
- USB (HID Compliant) Port
- Yes
- EPO Port
- Yes
- Battery Information
- Battery Characteristics
- Hot-swappable/Sealed
- Battery Chemistry
- Lead Acid
- Backup/Run Time (Full Load)
- 2.90 Minute
- Backup/Run Time (Half Load)
- 11.20 Minute
- Typical Battery Recharge Time
- 4 Hour
- Replaceable Battery
- Yes
- Environmental Conditions
- Maximum Operating Temperature
- 40°C
- Maximum Operating Elevation
- 1.50 km
- Maximum Storage Elevation
- 15 km
- Operating Humidity
- 95%
- Storage Relative Humidity
- 95%
- Sound Emission (A-Weighted)
- 62 dB(A)
- Thermal Dissipation
- 2047 BTU/h
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Form Factor
- Rack/Tower
- Rack Height
- 5U
- Height
- 213.5 mm
- Width
- 433 mm
- Depth
- 661 mm
- Miscellaneous
- Package Contents
- OLS10KERT5U 10000VA Rack/Tower UPS
- External Maintenance Bypass PDU
- Rackmount Rail
- Rackmount Ears
- Rail Kit
- Screw Kit
- Power Cord
- USB Cable
- Phone Line
- User's Manual
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
