- General Information
- Manufacturer
- Dell Technologies
- Manufacturer Website Address
- http://www.dell.com.au
- Brand Name
- Dell
- Product Line
- Smart-UPS
- Product Type
- Standby UPS
In addition to legendary reliability and manageability, Smart-UPS have extremely high efficiency at low, medium and high load levels making them ideal for today's multi-core or virtualized servers that have varying load consumption. Rack mounted Smart-UPS are ideal for powering Blade or density optimized servers in a distributed power protection environment as the primary or redundant protection. Smart-UPS models have long been considered the benchmark for all network and server UPS's. Smart-UPS feature a 16-segment LED display, extended range automatic voltage regulation (AVR), and pure sine wave output on battery.
- Boost and trim automatic voltage regulation (AVR)
- Intelligent battery management
- Power conditioning
- Temperature-compensated battery charging
- Automatic restart of loads after UPS shutdown
- Automatic self-test
- Cold-start capable
- Disconnected battery notification
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- AVR
- Yes
- Plug/Connector Type
- IEC 60320 C20
- Receptacle Type
- IEC 60320 C13
- IEC 60320 C19
- Receptacle Detail
- 8 x IEC 60320 C13
- 1 x IEC 60320 C19
- Power Description
- Load Capacity (VA)
- 3 kVA
- Load Capacity (Watt)
- 2.70 kW
- Input Voltage
- 230 V AC
- Input Voltage Range
- 150 V AC - 300 V AC
- Output Voltage
- 230 V AC
- Input Frequency
- 60 Hz
- Output Frequency
- 60 Hz
- Waveform Type
- Sine Wave
- Pure Sine Wave
- Surge Energy Rating
- 459 J
- Management
- Alarm
- Alarm
- Controls/Indicators
- Status Indicators
- LCD Display
- Interfaces/Ports
- Serial Port
- Yes
- EPO Port
- Yes
- USB (HID Compliant) Port
- Yes
- Battery Information
- Battery Chemistry
- Lead Acid
- Backup/Run Time (Full Load)
- 3 Minute
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Height
- 86 mm
- Width
- 480 mm
- Depth
- 683 mm
- Rack Height
- 2U
- Form Factor
- Rack-mountable
- Weight (Approximate)
- 44.28 kg
- Miscellaneous
- Package Contents
- Smart-UPS 3000VA Rack-mountable UPS
- Rack Mounting Kit
- Environmentally Friendly
- Yes
