NC591XB Security Camera
Long range IR 100 with a 18 times zoom lens. This camera is very impressive when patrolling large properties. You can set 255 presets for a patrol.
| Camera Type | PTZ |
| Image Sensor | 1/2.7″ Progressive Scan CMOS |
| Maximum Video Resolution Megapixels | 2 |
| Maximum Video Resolution | 1920 x 1080 |
| Lens | 5.0mm -90mm H.FOV 53.3 to 3.8° |
| Lens Type | Motorised Pan tilt and Zoom |
| Maximum Night IR Distance M | 100 |
| Video Compression | H.265 H.265 H.264 H.264 MJPEG |
| ONVIF depends on firmware version | ONVIF Profile S/G/T 21.12 or greater Http API |
| IP Rating | IP66 |
| Operating Environment | -20ºC to 60ºC 14ºF-140ºF Humidity 90 RH |
| Dimensions | Ø160 × 270 mm |
| Weight Net | 2.5 |
| Accessories | IV2488X |
| Power Supply | Power over Ethernet IEEE 802.3at DC12V |
| Power Consumption | <22W |
| Connectors | RJ-45 DC Power Input Audio In Audio Out Alarm in or out 1 reset button SD card slot. |
| Outdoor Use | Yes |
| IP Rating | IP66 |
| Vandal Resistant | Yes |
| Frame Rate at Resolution | 25 |
| Day/Night Mode | Auto |
| Image Enhancement | Flip mode Brightness Contrast Saturation Sharpness Hue Mirror Angle Flip Back Light White Balance Shutter Time Exposure Defog 3D Noise Reduction |
| Edge Recording microSD/SDHC Card | Micro SD/SDHC Card |
| Multiple Streams encode format | 3 Streams |
| Audio Streaming | Yes – input connector for external mic input connector for external speaker |
| Protocols | TCP/IP UDP HTTP HTTPS DHCP FTP RTP/RTSP DNS DDNS NTP PPPOE UPNP SMTP SMTP P2P QR code |
| Intelligent Video IVS | Face Recognition Human & Vehicle Detection Perimeter Intrusion Detection Line Crossing Detection Stationary Object Detection Crossing Counting Heat Map Crowd Density Detection Queue Length Detection License Plate Detection |
| Cloud option camera only | Dropbox |
| Software | Device Search/Config Tool Surveillance Client CMS/VMS Mobile app QR code |
| Power Over Ethernet | Yes |
| Ethernet | Ethernet 10/100 Base-T |
| In The Box | Free Software availible from FTP Printed quick user guide Installation template Mounting screws and plugs |
| Warranty | 3 Year Warranty |
Enquire now for special
