Moxa | Imc-101-S-Sc | Industrial 10/100BaseTX To 100BaseFX Media Converter | Single-Mode | SC Fiber Connector | 40 KM | 0 To 60°C Operating Temperature

  • Part: 2030142
$689.66

Availability

Out of Stock

#html-body [data-pb-style=FS1R0XO]{justify-content:flex-start;display:flex;flex-direction:column;background-position:left top;background-size:cover;background-repeat:no-repeat;background-attachment:scroll}

The Moxa IMC-101-S-SC is an industrial-grade Ethernet-to-fibre media converter, designed to reliably extend your 10/100BaseT(X) network over a 100BaseFX single-mode fibre optic cable with an SC connector. Built with a robust metal housing, it's ideal for harsh industrial environments, supporting an operating temperature range of 0 to 60°C. This converter features Link Fault Pass-Through (LFP) and Far-End Fault (FEF) detection for simplified network management and reduced downtime. With redundant power inputs (12 to 45VDC) and DIN-rail mounting, the IMC-101-S-SC offers a dependable solution for industrial automation, IP surveillance, and other demanding applications.

FEATURES

  • 1 x 10/100Mbps T(x) port and 1 x 100Mbps F(x) single-mode port with SC connector
  • Link Fault Pass-Through (LFP) and Far-End Fault (FEF) support
  • Power failure and port break alarm via relay output
  • Redundant power inputs (12 to 45 VDC)
  • Wide operating temperature range: 0 to 60°C
  • Robust metal housing with IP30 rating
  • DIN-rail and wall mountable

SPECIFICATIONS

  • Ethernet Interface: 1 x 10/100BaseT(X) auto-negotiation, auto-MDI/MDI-X, RJ45 connector
  • Fibre Interface: 1 x 100BaseFX, single-mode, SC connector
  • Fibre Distance: Up to 40km
  • Wavelength: 1310nm
  • Optical Power Output: 0 to -5 dBm
  • Optical Power Receive: -3 to -34 dBm
  • Link Budget: 29 dB
  • Magnetic Isolation Protection: 1.5kV (built-in)
  • Power Input: 12 to 45 VDC, redundant inputs via terminal block
  • Power Consumption: 200mA @ 12 to 45 VDC
  • Alarm Contact: Relay output for power failure and port break
  • Operating Temperature: 0 to 60°C
  • Storage Temperature: -40 to 85°C
  • Operating Humidity: 5 to 95% (non-condensing)
  • Housing: Metal, IP30 rated
  • Dimensions: 53.6 x 135 x 105 mm
  • Weight: 630g
  • Mounting: DIN-rail, Wall
  • Certifications: FCC, UL, CE, Class 1 Division 2/Zone 2, IECEx

WARRANTY

1-Year Limited Warranty
