Pro2 4X Source / 4X Zone Stereo Amp Power Amplifier - Inbuilt Dac

  • Part: 1189300
$359.00

Availability

In Stock

Pro2 PRO 1323 4- Source 4-Zone Stereo Audio Power Amplifier

With a diverse range of inputs, including digital (optical or coaxial) and dynamic microphone inputs, and the ability to adjust each zoneÕs volume independently, the PRO1323 is a quick and easy way of adding audio in up to four rooms. It also features a Loop-out for expanding to another unit, increasing the number of zones further!

Key Specifications :
  • Four-in and five-outIN: 1x Digital (Optical / Coaxial selectable), 1x RCA Stereo, 1x 3.5mm Stereo, 1x Dynamic Microphone inputOUT: 4 Speaker output + 1 Headphone output
  • Built-In audio digital to analogue converter (DAC): Audio DAC Lock indicator
  • Independent microphone level control
  • Individual speaker volume control
  • Provides line loop-out for expanding to more zones
  • Large detachable terminal block (supplied) for quick and easy installation: Screw terminals handle wire sizes from 24 to 12 gauge


Speaker Audio Power Amplifier (x4) Specifications :

  • Amplifier Type: Stereo Class-D
  • Output power: 15W(RMS) per channel (@ RL=4 ohm)
  • THD+N: 0.06 % (@ RL=8 ohm, f = 1 kHz)
  • Minimum Load Resistance: 4 ohm
  • Includes Speaker Protection circuit.


Earphone Audio Power Amplifier Specifications :
  • Output power:105mW(RMS) per channel
  • THD+N: 0.05 % (@ RL=16 ohm, f = 1 kHz)
  • Minimum Load Resistance: 16 ohm


General Specifications :

  • Power Consumed: 9A Max
  • Power Source: DC 12 Volts
  • Size (LxWxH): 285mm x 128mm x 43mm
  • Net Weight (Unit only): 0.8 Kg
